Z-6900 GPS Online Guard Tour Patrol Management System Guard Patrol Moving Path Tracking
Short Description:
Z-6900 is a GPS guard tour patrol management system that manage the patrol activity by real-time locating,can be customized for different functions, such as Real time+EVENT, GPS+Real time+EVENT, GPS+Real time+ITEM.
Spesification
- GPS Tracking: Easy to know guards live GPS and playback history trace on the cloud based software
- Strong Lighting: Multiple lighting mode for various lighting demands
- Panic Button for Guard: When PANIC button is being pressed device send an emergency alert to the monitoring center to ask for help
- Mobile APP Monitoring: Peace of mind from anywhere with PatrolMessenger APP, available in IOS & Android OS
Technical data
| 4G | 4G frequency | FDD-LTE:800/1800/2100/2600MHz(B1,B3,B7,B20)TDD-LTE:2600(B38)/1900/2400/2500MHz(B39,B40,B41) Can customize devices in your country’s 4G band as offered. |
| Sim card | Micro- sim card | |
| Data usage | 220kb/1,000 logs | |
| GPS | Precision | ≤ 50 meters(outdoor) |
| Data usage | 1.8 Mb per day(2s/coordinate) | |
| Feature | Reading technology | 125kHz ID tag |
| Reading range | 3cm-5cm | |
| Record | 80,000 logs | |
| Impact record | 32,000 logs | |
| SOS | Long press UP key for 3s | |
| Lighting | Distance | 50 meters |
| Lighting mode | High, medium, low, SOS and Strobe | |
| Battery | Battery capacity | 3,000mAh |
| Battery life | Charging 500 times | |
| Charging time | 5 hours | |
| Working time | 27hours | |
| Stand-by time | 68hours | |
| Battery level | 5 levels | |
| Screen | Size | 1.8 inch TFT display |
| Resolution | 160*128 | |
| Event | Total | 500 pcs |
| Per checkpoint | 1-15 pcs event | |
| Length | 31 letters | |
| Checkpoint | Storage maximum | 1,000 checkpoints |
| Name length | 19 letters | |
| Staff card | Storage maximum | 400 pcs |
| Name length | 15 letters | |
| Time | Booting time | 0.2s |
| Auto sleep time | 30s, 1m, 2m, 5m, 30m, 60m and never | |
| Flashlight time | 30s,1m,2m,5m,10m,30m | |
| USB | Communication port | Magnetic USB port |
| Transmission speed | 5000log/s | |
| System | Language | Chinese, traditional Chinese, English |
| Font | Big, small | |
| Dimension | Size | 118mm x 70mm x 30mm |
| Weight | 230g |
