SF1-MF Standalone RFID Access Control Reader

Short Description:

SF1-MF is a standalone RFID access control reader compatible with 13.56 MHz Mifare cards, including Mifare Classic, Plus, DesFire, Pro, UltraLight, NFC, and CPU cards. It supports up to 2,000 users and features a built-in relay for controlling doors or turnstiles. With IP66 weather resistance, tamper detection via a built-in Light Dependent Resistor (LDR), and pulse/toggle modes, the SF1-MF is ideal for offices, residential complexes, and industrial sites requiring a reliable standalone access control system.

Spesification

Technical Data

Spesification

  • Model: SF1-MF
  • Card Type Supported: 13.56 MHz Mifare (Classic, Plus, DesFire, Pro, UltraLight, NFC, CPU)
  • User Capacity: Up to 2,000 users
  • Relay Output: 1 built-in relay (NO/NC/COM)
  • Operating Voltage: 9–18V DC (idle current < 40 mA)
  • Reading Distance: 3–6 cm
  • Control Modes: Pulse mode, toggle mode
  • Tamper Detection: Built-in Light Dependent Resistor (LDR)

Technical data

ParameterDetail
ModelSF1-MF
Card Type13.56 MHz Mifare (Classic, Plus, DesFire, Pro, UltraLight, NFC, CPU)
User CapacityUp to 2,000 users
Relay Output1 built-in relay (NO/NC/COM)
Operating Voltage9–18V DC (idle current < 40 mA)
Reading Distance3–6 cm
Control ModesPulse mode, toggle mode
Tamper DetectionBuilt-in Light Dependent Resistor (LDR)
Weather ResistanceIP66 (suitable for indoor and outdoor use)
Operating Temperature-40 °C to 60 °C
Dimensions103 mm (H) × 48 mm (W) × 20 mm (D)
Unit Weight100 g
Housing MaterialABS (Acrylonitrile Butadiene Styrene)
ColorWhite
