SF1-ID Standalone RFID Access Control Reader (EM Version)
Short Description:
SF1-ID is a standalone RFID access control reader designed for 125 kHz EM/ID proximity cards. It can store up to 2,000 users and includes a built-in relay for controlling a door or turnstile directly without a separate controller. The unit features tamper detection, supports pulse or toggle output modes, and includes an IP66-rated weatherproof housing suitable for both indoor and outdoor installations.
Spesification
- Special Features: Waterproof / Weatherproof
- Storage: Memory Card
- Model Number: SF1
- User Capacity: 3000
- Card Type: 125Khz EM Card
- Resolution: 500DPI
Technical data
| Model | SF1-ID |
| Card Type | 125 kHz EM / ID |
| User Capacity | 2,000 users |
| Relay Output | 1 relay (NO / NC / COM) |
| Control Modes | Pulse mode, Toggle mode |
| Tamper Detection | Built-in LDR (Light Dependent Resistor) |
| Operating Voltage | 9–18 V DC |
| Reading Distance | 3–8 cm |
| Weather Resistance | IP66 (dust & water resistant) |
| Operating Temperature | –40 °C to +60 °C |
| Housing Material | ABS plastic |
| Dimensions | 103 × 48 × 20 mm |
