Sbutton 100-X Stainless Steel Exit Button
Short Description:
Sbutton 100-X is a stainless-steel exit button designed for use with access control systems. It provides a durable and vandal-resistant mechanical push button for unlocking doors from the secure side. The unit is suitable for indoor and outdoor installations and features a normally open/closed (NO/NC/COM) output that is compatible with most controllers, electric locks and door relays.
Spesification
- Special Features: Waterproof / Weatherproof
- Model Number: Sbutton 100
- Infrared Wavelength: 940 nm
- Timer Delay: 5s/10s / Toggle Mode
- Brand: Waterproof No Touch Exit Button
- Sensor Distance: 3~10cm (Adjustable)
- Working voltage: 10~24V DC
- Waterproof: IP66
- Output: NO/NC/COM
Technical data
| Model | Sbutton 100-X |
| Type | Mechanical exit push button |
| Output Contact | NO / NC / COM |
| Material | Stainless steel plate + metal button |
| Voltage Range | 12–24 V DC |
| Max. Current | 3 A |
| Installation | Surface mount |
| Weather Resistance | Yes (indoor / outdoor use) |
| Life Span | ≥ 500,000 operations |
| Dimensions | 86 × 86 × 25 mm |
