S1-X EM Metal Wiegand Reader
Short Description:
S1-X EM is a 125 kHz EM RFID access control reader designed for indoor and outdoor applications. It features a robust metal housing with IP66 protection against dust and water. The unit outputs Wiegand signals (default 26-bit) and supports external LED and buzzer connections, making it reliable for secure access control systems.
Spesification
- protocol ISO 14443A
- Frequency: 13.56Mhz
- Physical: ABS Shell
- Product name: S1-X (EM+MF)
- Reading Range: 2-6cm
- Card Type: ID Card & IC Card
Technical data
| Model | S1-X EM |
| Card Type | 125 kHz EM / ID cards |
| Output Format | Wiegand 26-bit (optional 34 / 37-bit) |
| Reading Distance | 3–8 cm |
| External LED & Buzzer | Yes |
| Housing Material | Vandal-resistant metal |
| Weather Resistance | IP66 (dust & water resistant) |
| Operating Voltage | 9–18 V DC |
| Operating Temperature | –40 °C to +60 °C |
| Standby Current | < 25 mA |
| Dimensions | 103 × 48 × 19 mm |
