K30 Standalone Access Controller
Short Description:
K30 is a fingerprint-based time attendance and access control terminal designed for small and medium sized businesses. It features a high-accuracy optical fingerprint sensor, supports RFID card (optional), and includes a built-in relay for door lock control. The terminal can store up to 1,000 fingerprints and 100,000 log records, and is equipped with a TCP/IP port for communication with PC software.
Spesification
- Authentication Methods : Fingerprint / PIN / (optional) RFID Card
- Fingerprint Capacity : 1,000 templates
- Log Capacity : 100,000 records
- Display : 2.8-inch TFT color screen
- Communication : TCP/IP, USB Host
- Power Supply : DC 12 V / 1 A
- Dimensions : 184 × 136 × 36 mm
Technical data
| Product Parameter | Parameter Description |
| S4A Model | K30 |
| Product Name | Standalone Access Controller |
| Card Type：EM | Quiescent Current:≤30mA |
| Operating voltage：DC12V±10% | Ambient temperature：-35～60℃ |
| Read Range: 3 – 150px | electric lock output: ≤ 3A |
| Humidity：10%- 90% RH | alarm time is adjustable0-3 minutes |
| Alarm output：≤ 20A | Opening hours：0-99 s |
| Unit Weight | 0.15KG |
| Standard Package | 100PCS |
| Carton Weight | 16KG |
| Carton Size | 57.5*47.5*23.7(cm |
