CR1-R EM Metal Wiegand Reader
Short Description:
CR1-R EM is a 125 kHz EM RFID access control reader designed for indoor and outdoor use. Featuring a robust metal housing with IP66 protection, it is resistant to dust and water. The unit provides Wiegand 26-bit output (optional 34/37-bit) and supports external LED and buzzer signals, making it reliable for secure access control systems.
Spesification
- Support Card: proximity cards
- Brand Name: Secukey/OEM
- Name: Mini RFID Reader
- Operating Voltage: 9~18V DC
- Waterproof: IP66
- Card type: 125KHz EM Card
Technical data
| Model | CR1-R EM |
| Card Type | 125 kHz EM / ID cards |
| Output Format | Wiegand 26-bit (optional 34 / 37-bit) |
| Reading Distance | 3–8 cm |
| External LED & Buzzer | Yes |
| Housing Material | Vandal-resistant metal |
| Weather Resistance | IP66 (dust & water resistant) |
| Operating Voltage | 9–18 V DC |
| Operating Temperature | –40 °C to +60 °C |
| Standby Current | < 25 mA |
| Dimensions | 103 × 48 × 19 mm |
